RCT-100T-000 Rogowski Coil

RCT-100T-000 Rogowski Coil current sensor measures AC current up to 5,000 Amps.

The RCT-100T-000 Rogowski Coil current sensor measures AC current up to 5,000 Amps. The flexible coil opens at the connector junction and can be installed on an existing cable or buss-bar in a matter of seconds.   The RCT-100T-000 comes without the integrator, and produces 70mV for every 1000A on the primary conductor, when operating at 60 Hz (at 50 Hz the output is 58.33 mV per 1000A).  See our RCT-100T-xxx if you would like a Rogowski coil with an integrator (which will output 333 mV at the rated input amperage).   This “Tear-drop” style design facilitates installations with limited electrical panel space. Electrical performance is equal to our standard RCT-1800-000 Series.
